-41%
B660 Motherboard (DDR5)
₹14,737.02 Save:₹10,041.00(41%)
Available in stock
Description
General |
|
|---|---|
| Product Type | Motherboard – micro ATX |
| Chipset Type | Intel B660 |
| Processor Socket | LGA1700 Socket |
| Max Processors Qty | 1 |
| Compatible Processors | (supports 12th Generation Intel Core / Pentium / Celeron) |
Supported RAM |
|
| Max Size | 64 GB |
| Technology | DDR4 |
| Bus Clock | 2133 MHz, 2666 MHz, 2933 MHz, 3200 MHz |
| Supported RAM Integrity Check | Non-ECC |
| Registered or Buffered | Unbuffered |
| Features | Dual channel memory architecture, Intel Extreme Memory Profiles (XMP) |
Audio |
|
| Type | HD Audio (8-channel) |
| Audio Codec | Realtek ALC897 |
| Compliant Standards | High Definition Audio |
LAN |
|
| Network Controller | Realtek RTL8125BG |
| Network Interfaces | 2.5 Gigabit Ethernet |
Expansion / Connectivity |
|
| Expansion Slots | 1 x CPU ¦ 2 x DIMM 288-pin ¦ 1 x PCIe 4.0 x16 ¦ 1 x PCIe 3.0 x1 |
| Storage Interfaces | SATA-600 -connectors: 4 x 7pin Serial ATA – RAID 0 / RAID 1 / RAID 10 / RAID 5 ¦ PCIe 4.0 -connectors: 1 x M.2 |
| Interfaces | 1 x HDMI ¦ 1 x VGA ¦ 4 x USB 3.2 Gen 1 ¦ 2 x USB 2.0 ¦ 1 x audio line-out – mini-jack ¦ 1 x microphone – mini-jack ¦ 1 x audio line-in – mini-jack ¦ 1 x LAN (2.5Gigabit Ethernet) ¦ 1 x PS/2 keyboard / mouse |
| Internal Interfaces | 4 x USB 2.0 – header ¦ 2 x USB 3.2 Gen 1 – header ¦ 1 x audio – header ¦ 1 x serial – header |
| Power Connectors | 24-pin main power connector, 8-pin ATX12V connector |
Features |
|
| BIOS Type | AMI |
| BIOS Features | Multilingual BIOS, UEFI BIOS, ACPI 6.4 support, SMBIOS 3.4 support |
| Hardware Features | Debug LED |
Miscellaneous |
|
| Included Accessories | Case badge, IO shield, M.2 clip |
| Cables Included | 2 x Serial ATA cable |
| Width | 24.4 cm |
| Depth | 22 cm |
